Single Seat Chassis (Kit)
The slightly more "dynamic" version of the frame, which is also considerably lower profile.
This was made possible by the use of newly designed aluminum profiles, which have a wall thickness of 4 mm and are powder-coated by us.
We have also introduced a new color, RAL 7016 anthracite gray, which visually matches the ITEM KH 40x40 profile very well, making the rig quite suitable for living rooms.
When in use, the frame stands stably on 8 adjustable feet.
The new profiles create control units that can be easily, yet securely, moved along the base frame. This allows the entire cockpit to be easily adjusted to different body sizes.
The profiles for the seat shells have a 4° incline for a more comfortable seating position.
Racing seat shells or the recommended Smart Seat result in a seat height of approximately 33-35 cm to the pedal level, which corresponds to most real helicopters.
If a Collective with a base is selected, the 8-axis controller is included. This is sufficient for all axes of a helicopter.
The Cyclic base includes a BTU-32 for the buttons on the grips.
The pedal plate has a cutout for Type 2 pedals, but thanks to the aluminum heel rests, it can also be used directly with the Type 8 and Type 3 series.
The Type 3 pedals additionally feature stepless brake plates for wheeled landing gear (sim) with two individual axes and 5kg gas springs.
The Collective level can be fixed in several positions along the seat line using the large HPL plate.
Currently, all existing helicopter types can be combined with the frame.
And to match the frame, all visible metal parts are powder-coated. Currently, RAL 7016 (anthracite gray) or RAL 9005 (matte black) are available.
A seat shell or car seat is required for completion. The mounting axle spacing is 405 mm.
We recommend a Smart 451 seat, which can even be used with the existing seat rail with minimal modifications.
The optional rear-mounted casters and front handle allow for easy maneuvering and parking of the frame.
Customized platforms are also available; please inquire for Details.
